Muncie SG PTO Series
The very first Power Take-Offs were single gear units. The SG is perfectly suited for light to medium duty applications like small dump trucks and farm hoists. Output shaft of a single gear PTO is close to the transmission, so direct mount pump flanges are not available.
Key features and benefits
- Light weight and quiet operation
- Compact Housing with Easy Installation
- Simple Design allows for easy, inexpensive service
Common applications
- Single/Tandem Axle Dump Trucks
- Farm Hoists
- Light Duty Wreckers
- Tilt-Back Car Carriers
Specifications
| Muncie SG Series Specifications | |
|---|---|
| Housing Construction | Aluminum |
| Speed Ratios | 1 |
| Output Shaft Options | 7/8" Rd. |
| Gear Pitches Offered | 21 |
| Shift Types | Cable Only |
| Assembly Arrangements | 2 |
| Approximate Weight | 7 lbs. (3.2 Kg.) |
| Max Torque | |
| Intermittent | 130 lbs.ft. (176 Nm) |
| Continuous | 91 lbs.ft. (123 Nm) |
| MAX HP (@ 1,000 RPM) | |
| Intermittent | 25 HP (19 kW) |
| Continuous | 17 HP (12.7 kW) |
