Muncie CS41 PTO
The CS41 Series PTO is an extra heavy duty, Clutch Shift PTO designed for Allison World and Caterpillar automatic transmissions. The CS41 Series PTO is engaged by a solenoid activated, wet clutch pack and features a remotely mounted solenoid for a more compact installation. The CS41 is rated to 600 lb.ft. torque/intermittent and 420 lb.ft. torque/continuous.
Key features and benefits
- Precision ground gears: High torque capacity with quiet operation
- Extra large bearings & components: High torque and durability
- 1410 series remote mount output shaft: For remote pump drives
- S.A.E. "C" and DIN 5462 direct mount options: Fits most popular pumps requiring high power input
- Rotatable direct mount flanges: Allows pump to be positioned for maximum clearance
- Two assembly arrangements: Allows the PTO to be mounted shaft high or low on either side of the transmission
- Standard pressure lubrication: No extra cost
Common applications
- Refuse Equipment
- Cranes
- Fire Equipment
- Construction Equipment
Specifications
| Muncie CS41 PTO Series | |
|---|---|
| Housing Construction | Ductile Iron |
| Speed Ratios | 3 |
| Output Shaft Options | 3 |
| Rotatable Pump Flange | Standard |
| Assembly Arrangements | 2 |
| Approximate Weight | 69 lbs. (31.3 Kg.) |
| Max Torque | |
| Intermittent | 600 lbs.ft. (813 Nm) |
| Continuous | 420 lbs.ft. (569 Nm) |
| MAX HP (@ 1,000 RPM) | |
| Intermittent | 114 HP (85 kW) |
| Continuous | 80 HP (60 kW) |
Muncie CS41 manuals and brochures
Free PDF downloads of the Muncie literature for this series.
PDFMuncie CS41 Series Brochure
595 KBPDFMuncie CS41 Series PTO Parts Breakdown
817 KBPDFMuncie CS41 Series Installation Manual
6.8 MB
595 KBPDFMuncie CS41 Series PTO Parts Breakdown
817 KBPDFMuncie CS41 Series Installation Manual
6.8 MB
Buy Muncie CS41 PTO parts online
Our online store at pgttruckparts.com carries Muncie power take-offs, rebuild kits, seal kits, shifters and the individual parts, priced and ready to order:
- Muncie CS41 series interactive parts list: every callout on the exploded view is a part you can price and order
- Muncie CS41 series PTO units
- All Muncie PTO parts
- All Muncie PTO units
Need a Muncie PTO or a part for one?
Give us the model number from the PTO tag, or the part number or item number from the manual. We will price it and tell you when it can ship.
