Muncie FR / FA PTO Series
The Muncie FR FA PTO Series, power take-offs were designed in cooperation with Ford Motor Company's engineers to fit the 5R110 TorqShift and 4R100 automatic transmissions.
There are two models for each series available: the FR63 and FA62 for two wheel drive vehicles, and the FR67 and FA64 for four wheel drive. The FR63, FR67, and FA62 are available in both remote and direct mount pump models. The FA64 is available as a shaft front, direct mount pump model only. All are wet clutch type power take-offs.
Key features and benefits
- Integral solenoid design (FR67): Reduces installation time
- Solenoid activated clutch shift: Positive, no "gear clash" engagement
- Helical gearing throughout (FA): Quiet operation
- Pre-configured wiring harness: Easy, plug-in installation
- Remote and direct mount models: Versatile pump mounting
Common applications
- Dump Trucks
- Wreckers
- Snow Plows
- Aerial Bucket Trucks
- Tilt Back Lift Carriers
- Lift Gate
Specifications
| Muncie FA PTO Series | Muncie FR PTO Series | |
|---|---|---|
| Housing Construction | Ductile Iron | Aluminum |
| Largest Pump Offered | 2.9 cu. in. | 2.0 cu.in. |
| Output Shaft Options | 3/4"- 11 spline | |
| Rotatable Pump Flange | Standard | |
| Approximate Weight | 34 lbs. (15.42 Kg.) | |
Muncie FR FA manuals and brochures
Free PDF downloads of the Muncie literature for this series.
560 KBPDFMuncie FR/FA Series PTO Parts Breakdown
3.5 MBPDFMuncie FR/FA Series PTO Installation Manual
8.5 MB
Buy Muncie FR FA PTO parts online
Our online store at pgttruckparts.com carries Muncie power take-offs, rebuild kits, seal kits, shifters and the individual parts, priced and ready to order:
- Muncie FR63 series interactive parts list: every callout on the exploded view is a part you can price and order
- Muncie FR67 series interactive parts list: every callout on the exploded view is a part you can price and order
- Muncie FA series interactive parts list: every callout on the exploded view is a part you can price and order
- Muncie FR67 series PTO units
- All Muncie PTO parts
- All Muncie PTO units
Need a Muncie PTO or a part for one?
Give us the model number from the PTO tag, or the part number or item number from the manual. We will price it and tell you when it can ship.
