Muncie CS6 / CS8 PTO
The CS6 and CS8 series are Clutch Shift PTOs designed to work great on Allison 1000 & 2000 series automatics and many current manual transmissions. Like all of Muncie's "Clutch Shift" line of PTOs, the CS6/8 offers popular direct mount pump options as well as Muncie's patented shaft brake, a standard feature. An upgraded multi-disk clutch brake can be used where absolute shaft stoppage is required.
A recent option is the gear reducer box (CSGB200-125) which reduces the output shaft speed by 50%, making it an ideal option for low speed applications.
Clutch Shift PTOs used in conjunction with the SPD-1000A, System Protection Device, can greatly reduce expensive transmission and equipment repairs caused by exceeding operational limits. In addition, operating restrictions can be implemented to ensure the safety of the equipment operator and bystanders.
Key features and benefits
- 23 transmission input gears: Fits most popular automatic and manual transmissions
- Three remote mount output shafts in keyed and flange types: Versatility for remote pump drives
- S.A.E. "A", "B", and "BB"; DIN 5462 direct mount pump options: Fits most popular pumps
- Rotatable direct mount flanges: Allows pump to be positioned for maximum clearance
- Patented Muncie drag brake: Prevents shaft rotation in "OFF" mode
- Optional pulse generator: Lets System Protection Device monitor PTO shaft speed
Common applications
- Refuse Equipment
- Lube Trucks
- Digger Derricks
- Aerial Bucket Trucks
- Ice And Snow Control Trucks
Specifications
| Muncie CS6 / CS8 PTO Series Specifications | |
|---|---|
| Housing Construction | Ductile Iron |
| Speed Ratios | 7 |
| Output Shaft Options | 12 |
| Rotatable Pump Flange | Standard |
| Assembly Arrangements | 4 |
| Drag Brake | Standard |
| Approximate Weight | 47 lbs. (21.3 Kg.) |
| Max Torque | |
| Intermittent | 300 lbs.ft. (407 Nm) |
| Continuous | 210 lbs.ft. (285 Nm) |
| MAX HP (@ 1,000 RPM) | |
| Intermittent | 57 HP (43 kW) |
| Continuous | 40 HP (30 kW) |
Muncie CS6 CS8 manuals and brochures
Free PDF downloads of the Muncie literature for this series.
1.1 MBPDFMuncie CS6 / CS8 Series Parts Breakdown
8.1 MBPDFMuncie CS6 / CS8 PTO Installation Manual
3.2 MB
Buy Muncie CS6 CS8 PTO parts online
Our online store at pgttruckparts.com carries Muncie power take-offs, rebuild kits, seal kits, shifters and the individual parts, priced and ready to order:
- Muncie CS6 series interactive parts list: every callout on the exploded view is a part you can price and order
- Muncie CS8 series interactive parts list: every callout on the exploded view is a part you can price and order
- Muncie CB6 series interactive parts list: every callout on the exploded view is a part you can price and order
- Muncie CB8 series interactive parts list: every callout on the exploded view is a part you can price and order
- Muncie CS6 series PTO units
- All Muncie PTO parts
- All Muncie PTO units
Need a Muncie PTO or a part for one?
Give us the model number from the PTO tag, or the part number or item number from the manual. We will price it and tell you when it can ship.
